Technology

A laser blood-acquisition device.

Energy-based capillary access, not a steel lancet. Built on Er:YAG laser optics and designed for a shallow, point-of-care draw.

Er:YAG · 2940 nm ~0.25 mm Rx Only
Aponex dock with the ORTIV laser blood-acquisition device

How it works

Energy based invasion, no sharps.

An energy pulse opens a micro-channel in the skin to access a capillary sample, designed for a shallow, lancet-free draw.

STEP 01

Energy pulse

A focused Er:YAG laser pulse is applied to the skin surface, with intensity set by the clinician.

STEP 02

Micro-channel

The pulse forms a micro-channel designed to reach approximately 0.25 mm, without a steel lancet.

STEP 03

Capillary sample

A capillary whole-blood sample surfaces for point-of-care measurement.

EPIDERMIS DERMIS SUBCUTIS 0 mm 1.0 2.0 APONEX PENETRATION ~0.25 mm Calcaneal safe-depth limit (neonatal) 2.4 mm ~10× shallower

Illustrative, not to clinical scale. The ~0.25 mm penetration depth shown is a theoretical estimate from optical-ablation modeling, not a measured clinical result, and can vary with skin type, anatomical site, and use conditions. The 2.4 mm reference is the maximum recommended neonatal heel-puncture depth (Blumenfeld et al., Lancet 1979; WHO phlebotomy guidelines). Neonatal and pediatric use is under development and not yet cleared. Refer to the cleared instructions for use, or email contact@aponexlaserdx.com for more information.

Aponex penetration~0.25 mm
Calcaneal safe-depth limit (neonatal)2.4 mm

~10× shallower.

Illustrative, not to clinical scale. Penetration depth is a theoretical estimate and varies by skin type and use conditions. Neonatal & pediatric use is under development and not yet cleared.

Regulatory information

Intended use & safety.

Intended use

ORTIV is a portable, battery-operated laser lancing device indicated for obtaining capillary blood samples in both institutional and at-home settings. Prescription use only (Rx Only). Refer to the product labeling and instructions for use for the complete cleared indications, the patient population, and the use environment supported in your region.

Indications

Indicated for capillary blood sampling at the fingers, in institutional and at-home settings.

Safety information

ORTIV is a Class 3R laser product (IEC 60825-1) using a pulsed Er:YAG source at 2940 nm. Prescription use only. For use by trained personnel per the Instructions for Use; follow your facility's infection-control and sharps/biohazard protocols.

  • Use only as described in the Instructions for Use.
  • Do not direct the laser aperture toward the eyes; observe stated laser-safety precautions.
  • Follow standard precautions for handling blood and potentially infectious materials.
  • Report any adverse event or device malfunction to the manufacturer and FDA (MedWatch / 21 CFR Part 803).
